Description
- Brand Name: MiCODUS
- Origin: Mainland China
- GPS Geographic Location: europe
- Voltage: 12V
- Battery Life: 5 To 9 Hours
- Item Size: 89(L) x 37(W) x 12(H)
- Special Feature: Remote Control
- GPS type: GPS Tracker
- Model Name: MV401G
- Screen Size: No screen
- Gps Module: Yes
- Out Power: 0.5w
- Certification: CE, FCC
- Tpye: GPS Tracker Car
- Unit weight: 32g
- Model Name: 4G LTE Vehicle GPS Tracker MV401G
- Built-in Battery: Embedded 3.7V/140mAh battery
- Item size: 89(L)X 37(W) X 12(H)
- GPS Geographic Location: Global use
- Voltage: 12/ 24/ 36/ 48/ 60/ 72 VDC
- Work Current: GPRS(500mA);WCDMA(700mA); LTE(800mA)
- Standby Current: Power off(20uA);Sleep(3mA);Idel(22mA)
- Satellite Accuracy: 5-15m
- LBS Accuracy: >100m
- GPS Band: 1575MHz
- GSM Band: B2/B3/B5/B8
- WCDMA Band: B1/B2/B5/B8
- LTE Band: FDD(B1/B2/B3/B4/B5/B7/B8 /B28); TDD(B40)
- Battery Capacity: 140mAh
- Net Weight: 46g
- Special Function: Speed Alarm and Cut Off Fuel When Overspeed
- Optional Accessories: SOS Button, iButton, Temperature Sensor, External Battery, BLE Host
IMPORTANT, PLEASE NOTE:
1. Our Spionlink Sim card only support to work with the following countries, It doesn’t work in other countries.
Russian Federation,Belgium, Bulgaria, Cyprus, Croatia, Czechia, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, United Kingdom,Switzerland ,USA, Canada, Mexico, Puerto Rico.
If you will not use this tracker in these above countries, please choose the device tracker only, and buy sim card from your country.
2. Our Spionlink is only data sim card, not support sms and call functions.
3. Spionlink only 1MB free data in it, after testing you need top up it.
4.For more information about our Spionlink sim card recharge, please refer to the description at the bottom of the details.
5.(1)You can login to our SIM card website directly to recharge:
http://www.spionlink.com/
(2)Scan the QR code on the SIM card to charge
6.Standard（No SOS,Relay)
MV401G
4G Network
GPS Band:1575MHz;
GSM Band:B2/B3/B5/B8;
WCDMA Band:B1/B2/B5/B8;
LTE Band:FDD(B1/B2/B3/B4/B5/B7/B8/B28); TDD(B40).
Super multi positioning system
Accurate positioning wherever you are!
（GPS/Beidou/Glonass/Galileo/LBS）
Monitor anytime, anywhere
We can track our car by SMS/Phone/Tablet/Computer.
Operating Voltage:9-72v
MV401G is suitable for all cars in the market,So a TK419 can be used in all the cars in your home!
Remote Control
When an emergency occurs, such as stealing a car, we can remotely control our car and prevent theft from happening in time.
Cut oil if overspeed
When the car is overspeed drving,TK419 will detect the speed, once it exceeds the range we set, it will cut off the oil to protect our safety!and TK419 will send a overspeed message to admin!
Move alarm
Set an area, no matter where the car is, as long as the car leaves the range we set, we will receive an alarm message, which may mean that our car is being stolen.
Shock alarm
The occurrence of a vibration alarm is usually an accident in the car. Or someone is stealing a car.
Low battery alarm
This device must be connected to an external power source. If our device prompts a low battery alarm, The reason may be that the device’s line has been cut, or someone has taken the device away. We need to check if there are any problems with our car.
Waterproof
Geo-fence
Regional protection of the safety of the car!
SOS alarm
In an emergency, MV401G will send out a SOS message!
Platform and mobile app
LIFETIME FREE
Website:http://www.micodus.net
Mobile APP:scan the QR code in the image and download the mobile app,log in with the device’s id (above device sticker) number and password; (the original password is :123456. You can modify it).
Overviews
MV401G GPS Tracker, we can monitor your vehicle by GPS satellite positioning system, GPRS/WCDMA/LTE FDD network communication and Internet, a real-time remote location and control of vehicles can be achieved through a powerful service platform.It plays a significant role in logistics and cold chain, helping customers to achieve transparent management, reduce costs, ensure safety, and improve efficiency.
Main function
1.Support GSM/ WCDMA/ LTE FDD;
2.Support GPS/ Beidou/ Glonass/ Galileo/Qzss. A-GPS / LBS for aiding;
3. Data Uploaded by GPRS/WCDMA/LTE FDD regularly, check by Web/APP/SMS;
4. Super Wide Input Voltage：9-72V DC;
5.ACC status detection;
6.Support SOS, External battery, iButton (Hardware customization);
7. Serial port, also can be GPIO port(Firm ware Customization);
8. Built-in battery, power disconnect alarm &low battery alarm;
9. Built-in G-sensor, vibration, collision and falling alarm;
10. GEO-fence alarm, speed & shift alarm;
11. Relay to cut engine, auto cut engine when overspeed and recover when normal speed;
12. EELINK protocol 2.0, Firmware OTA;
13. USB connect with PC to configure device;
14. Waterproof level.
Trouble shooting
Cannot connect platform
device is never online on the position server when installed at the first time. Please check device:
1）If power cables are wired correctly? Pay attention
to not connect them to controlling cables of vehicle.
2）If SIM card is installed correctly? Please refer to
the installation instructions.
3）Check the status of LED indicators. If device is OK, red LED and blue LED will intermittently flick.
4）Inquiry parameters of device via commands and check replied parameters.
Offline status
First check if LED indicators are OK, if cannot check them, you can check SIM card following next steps:
1）call SIM card of device and check if you can hear
connecting ring.
2）Check if vehicle is in the area where there is no GSM/WCDMA/LTE signal.
3）Check if one device or all devices are offline in the area . If all devices are offline, you should ask operator If network is OK.
4）Check if SIM card has enough balance.
5）If device becomes offline on the last day of one month, please check GPRS is closed or not.
6）Inquiry parameters of device via commands and check replied parameters.
No positioned
If the GPS is active, but device cannot be positioned for long time, please check device:
1）If the vehicle is in the place where there is no
GPS signal.
2）The upside of device should be installed with face toward the sky.
3）The GSM/WCDMA/LTE and GPS signal may be weakened if device is installed in the place with electromagnetic wave absorption material(such as metal blocks), special attention should be paid if
there is metal thermal insulation layer or heating layer on the front windshield, so that the position accuracy will decline, and the severe ones will not be positioned.
Position drift
1.Serious position drift will be found in places where GPS signal is poor. Please drive the vehicle to the open places.
Commands receiving abnormally
1）Check the commands format.
2）Check if the vehicle is in the places where there is GSM signal.
3）Check if the SIM card is properly installed.
